AIRSKIN for KUKA

Upgrade KUKA's wide portfolio of industrial robots to build truly fenceless applications with AIRSKIN

Best of 2 worlds

Benefit from the KUKA eco-system and its wide range of robots & tools. Combine it with AIRSKIN to reduce your robot footprint by up to 90%.

Add safety

Choose the right robot & tool for your application and then add AIRSKIN to make a safe, truly fenceless collaborative application.

Speed

Benefit from fast industrial robots with  collaborative speeds of up to 2 m/s, with a payload up to 300 kg and reach from 900 to 3100 mm.

Fenceless KUKA Agilus

Our pressure-sensitive (tactile) AIRSKIN upgrades the Agilus robots to fast and safe collaborative applications.

The AIRSKIN Safetyflange provides the necessary safety to the EoATs and thus provides a superior alternative to cobots. Available with up to 9 kg payload and 900 to 1100 mm reach, these Agilus robots become fenceless with AIRSKIN and provide your cells with the best of both worlds.

KUKA AG2 1100_PO01_P1_V01_1280-1

Fenceless KUKA Cybertech

For more payload and reach, the entire Cybertech 2 series is available with AIRSKIN. Cybertech 2 with a payload of up to 20 kg and reaches of 1610, 1810 and 2010 mm.

Features include the integrated energy chain underneath the AIRSKIN for all your cables and hoses. The design is optimized for installation and maintenance.

With the newly developed AIRSKIN Safetyflange Pro for palletizing applications, the Cybertech with AIRSKIN is a truly unique solution on the market for parcels up to 20 kg and up to 10 picks per minute applications.

Unbent-3-1

Fenceless KUKA Iontec

AIRSKIN transforms the KUKA Iontec, with a payload capacity of up to 70 kg, into a fully collaborative industrial robot.

With a reach of up to 2.5 meters, the KR Iontec offers unparalleled flexibility, featuring the best work envelope in its class and versatile mounting options.

KU_IT_202408_04

Fenceless KUKA Quantec

AIRSKIN turns a KUKA Quantec into the largest fenceless/collaborative robot to date.

Combining our soft pressure sensitive safety skin with a high performance industrial robot gives you the best of both worlds – high payload and reach with proven robustness and precision plus fenceless operation – opening up limitless possibilities for fenceless automation.

Unbenbbt-1-2

Discuss your needs with our safety experts

Get in touch
 →

Frequently asked questions

  • AIRSKIN is currently available for the KUKA model series Agilus, Cybertech, Iontec and Quantec as well as for the Stäubli POWER Cobot series TX2touch-60 and TX2touch-90 and Yaskawa MOTOMAN GP180.

    There are also AIRSKIN Modules for individual solutions and the AIRSKIN Safetyflange for safeguarding any gripper/tool.

  • We are focussed on providing AIRSKIN for the wide range of medium and heavy robots. Our current portfolio consists of designs for several KUKA, Stäubli and Yaskawa robots. We are permanently in contact with other robot manufacturers to increase our product portfolio. For more information please ask our sales managers.

  • Sure. They can help you with your purchase and installation of AIRSKIN.
